Pressure, Flow Rate and Shear Stress Calculator

To size a microfluidic system, it’s necessary to match the microfluidic resistance and pressure to the desired fluid flow rate or shear stress. Two different microfluidic resistances are important: the resistance of the fluidic path, i.e. tubings, fittings, instrument or sensor in line, and the resistance of the chip itself. Fluid properties are also a parameter to be taken into account.

Why is flow rate monitoring important in a microfluidic system?

Flow rate can be defined as the volume of solution that flows through the cross-section of the channel during one time unit. The flow rate influences the volume of solution needed for the experiment, but also the dynamics of the system, such as diffusion, particle speed, or the flow regime.

Why do I need to calculate the shear stress in a microfluidic system?

Shear stress in microfluidics is defined as the component of stress created by fluid friction in the microchannels. Shear stress is an important parameter, especially in biological studies. Forces are everywhere in the body and cells sense these forces. It can trigger signalling cascades that can result in different gene expression or gene silencing. Forces govern cell fate and function and it is directly related to the flow rate.

Shear stress is induced by fluid flow over a stationary phase, which creates a frictional force between the fluid layer and the solid. Shear stress are forces applied tangentially  to the surface and defined as:

For example, shear stress is studied a lot in hemodynamics, the flow of blood. When blood flows through vessels, it exerts pressure on the vessels walls, in particular on the endothelial cells covering the inner part of the blood vessels. In dynamic cell culture, shear stress is then a particularly important parameter. As mentioned before, it is closely linked to the flow rate with the fundamental formula: Navier-Stokes equation (demonstrated here).

In microfluidics, viscous forces predominate over inertial forces, leading to laminar flow. By simplifying the Navier-Stokes equation and assuming that the flow is laminar, we can say that the flow is steady and unidirectional. This assumption leads to the Stokes equation that can be resolved using the geometry of the channel.

In a circular channel, we get the final Hagen-Poiseuille equation:

where ΔP is the pressure drop, Q the flow rate (m³/s). Rₕ is the hydraulic resistance of the channel, it can be calculated from the dynamic viscosity of the fluid (𝜂 in Pa.s) and the channel shape and dimensions (r is the radius of a circular channel and L the length in m).

In the case of a very wide rectangular channel (or parallel plates), where a>>b (with a being the width of the channel and b the height), the simplified equation is:

How to measure flow rate and resistance?

• To measure flow rate accurately in microfluidic systems, Elveflow offers two complementary flow sensor technologies: the Microfluidic Flow Sensor (MFS) and the Bronkhorst Flow Sensor (BFS). Both sensors integrate seamlessly with the OB1 pressure controller, allowing real-time feedback control and ensuring consistent, reproducible flow conditions in your microfluidic experiments.

• • The MFS uses thermal mass flow sensing to provide ultra-fast and precise liquid flow measurements down to the nanoliter-per-minute range, ideal for monitoring small-volume experiments and rapid flow changes.
  • The BFS, based on the Coriolis principle, directly measures the mass flow rate by detecting the phase shift of a vibrating tube as fluid passes through it, making the measurement independent of fluid properties such as viscosity, density, or temperature.
• Resistance can not be measured but needs to be calculated (find the full application note here). Either done knowing the geometry of the microfluidic path or by using the Hagen-Poiseuille equation, knowing the pressure and the flow rate in the system.

Why use pressure-driven flow control with Elveflow pressure controller and flow sensor?

Using pressure-driven flow control with the Elveflow OB1 pressure controller and MFS or BFS flow sensor offers the most accurate and responsive way to generate and monitor flow rates in microfluidic systems. Unlike syringe or peristaltic pumps, pressure-driven systems ensure stable, pulse-free flow even at extremely low flow rates. The OB1, when paired with the MFS or BFS flow sensor and controlled through the Elveflow Smart Interface (ESI) software, allows users to monitor and adjust flow rate in real time with exceptional precision.

To select the optimal OB1 pressure range, it is essential to first define the target flow rate and estimate the corresponding pressure drop, which depends on the fluidic resistance of your system. This resistance is determined by the geometry of the microfluidic chip and tubing, as well as the fluid properties (see the formulas above). In simple configuration as one inlet one outlet design, by calculating and comparing the contributions of the chip and tubing, you can identify the dominant resistance and refine your system parameters.

Our calculator helps users determine the pressure, flow rate, and shear stress required to achieve their desired experimental conditions. As a result, it gives an initial indication of the working pressure and flow rate and select the most suitable OB1 pressure controller or flow sensor for their specific microfluidic setup.

Before using the calculator, a few parameters should be defined:

• Know the dimensions and design of your microfluidic chip.
• Determine whether the tubing resistance is negligible compared to the device resistance.
• Identify at least one experimental parameter, either the desired flow rate, pressure, or shear stress.

Once these inputs are provided, the calculator will estimate the corresponding pressure range, flow rate, and shear stress. We hope this tool helps you better understand these key concepts and simplifies the selection of your Elveflow system. For any questions or personalized guidance, feel free to contact our team.

Let’s use the flow rate calculator

This calculator is made of four parts.

In Part 1, input fluid properties like viscosity and density. The more viscous the fluid, the greater the pressure to be applied for a given flow rate.

Part 2 is not mandatory, you can use it to calculate the hydraulic resistance inside tubings based on their length, and inner diameter.

Part 3 focuses on your microfluidic chip (PDMS, glass, polymers…). You can describe the channel geometry in a section of the chip, to give its resistance and shear stress. You can use it as a reverse tool if you have a specific shear stress value and want to know the best flow rate to apply.

Part 4 gives results and recommendations to help you choose the perfect flow sensor and pressure controller, and advice to improve flow stability with microfluidic resistance length and diameter. Test it! These values are provided for informational purposes only. If you have any questions, please contact our experts.
