MICROFLUIDIC RESERVOIRS

Here is a compatibility chart of the use of the reservoirs with the different pressure ranges of the OB1 MK3+.

*not tested in these conditions
** The reservoir passed the pressure resistance tests in these conditions; nevertheless, Elveflow doesn’t recommend using it as they are sensitive to mechanical damage
Non-contractual information, may be changed without notice

Kit content

• • Microfluidic XXS On Chip Reservoirs
    • Tip 23G 1/2″ Blunt End (x5)
    • 1 mL column in polypropylene with Luer-Lock end (autoclavable) (x5)
    • Toric joint 8 mm x 1 mm (x5)
    • Male Luer-Lock to 3/32″ barbed connector (x5)

• • Microfluidic Reservoir for 1.5 mL Eppendorf® – XS
    • Eppendorf® tube microfluidic adapter (x1) (Hard anodized aluminum body)
    • Eppendorf® tubes (4x) included

• • Microfluidic Reservoir for 15 mL Falcon® – S
    • 15mL Falcon® tube microfluidic adapter (x1) (Hard anodized aluminum body)
    • 15mL Falcon® tubes (4x) included

• • Microfluidic Reservoir for 50 mL Falcon® – M
    • 50mL Falcon® tube microfluidic adapter (x1) (Hard anodized aluminum body)
    • 50mL Falcon® tubes (4x) included

• • Microfluidic Reservoir for 100 mL Bottles – L
    • Bottle cap with two ports (x1) (Delrin body) and Viton o-ring seal
    • 100 mL glass bottle (x1)
    • Protective net (x1)

• Microfluidic Reservoir for 150 mL Bottles – HP
  • Bottle cap with two ports (x1) (PTFE body)
  • 350 mL glass bottle (x1)
  • Protective net (x1)

  • Bottle holder

• Microfluidic Reservoir for 350 mL Bottles – HP
  • Bottle cap with two ports (x1) (PTFE body)
  • 350 mL glass bottle (x1)
  • Protective net (x1)

  • Bottle holder

Note: these products do not come with 1/4″-28 fittings or microfluidic tubing.

Safety warning

Working with systems under pressure above atmospheric pressure presents a safety risk, especially when working with hazardous liquids and gases.

Elveflow cannot guarantee the strength of the provided reservoirs beyond atmospheric pressure due to the nature of their material, transportation, and end-user handling methods. It is thus the responsibility of the end-user to take necessary precautions to ensure their safety, including careful handling and operation and wearing personal protective equipment.
