Reservoir
Reservoir XXS on chip
Microfluidic vial for reagent savingSmallest reservoir for microfluidics
800 µL
No dead volume
Directly plug on your chip: no tubing!
Contact us
At a glance
Reservoir XXS on chip is an 800 µL microfluidic vial for reagent saving that plugs directly into the chip inlet without tubing. The reservoir is used with a pressure source that pressurizes it and forces the liquid through microfluidic tubing into the microfluidic system. The reservoir has no dead volume.
- Connection
- Male luer lock cap and female luer slip adapter
- Standard content
- Tubes, o-ring seals, 23G 1/2" blunt needle tips, Luer Lock barb 3/32" connectors (x5 each)
Features & Benefits
These microfluidic reservoirs are designed to be plugged directly into the chip’s inlet without using any tubing. They are intended to be used with a pressure source, pressurizing the reservoir and forcing the liquid through microfluidic tubing and into the microfluidic system.
- 800 µL tube with male luer lock cap and female luer slip adapter (x5)
- o-ring seal (x5)
- Needle Tip 23G 1/2“ blunt end (x5)
- Luer Lock barb 3/32” connector (x5)
